Model NO.	MD300/500/900/1100
Structure	Multistage Pump
Assembly	Booster Pump
Power	Electric
Start Up	Electric Pump
Type	Booster Pump
Application	Booster Pump
Industry	Household Pump
Media	Clean Water
Performance	Automatic Pump
Theory	Centrifugal Pump
Sensor	Pressure Switch
Liquid	Clean Water
Max Suction	6m
Outlet	1"
Transport Package	Single Brown Box Packing
Specification	40x18x23.5/42.5x18.5x23.5
Trademark	Mepcato
Origin	China
HS Code	8413709990
Production Capacity	20000PCS/Month

Product Description

MD Electronic Control Booster Pump Description

Features

Operation Conditions

Operation Conditions

1. Suitable liquid: potable water or other clean or non-corrosive liquids.
2. Ambient temperature: Max. +40°C
3. Liquid temperature: +4°C ~ +90°C
4. Relative humidity: Max. 85% (RH)

Performance

Model	Input Power	Output Power	Voltage/ Frequency	Outlet/ Inlet	Max Suction	Max Head	Max Capacity		L x W x H
	Watt	Watt	V/Hz	inch	m	m	L/min	m3/h	cm
MD300/MDH300	300	200	220-240V/ 50Hz	1"	6	26	65	3.8	40x18x23.5
MD500/MDH500	680	500				31	84	5
MD900/MDH900	950	800				35	105	6.3
MD1100/MDH1100	1100	950				47	105	6.3	42.5x18.5x23.5

* Voltage and frequency available upon request.

Packaging & Shipping

Company Profile

Our Advantages

1. Highly efficient motor design for 24 hours continuous duty use.2. Adopt Italian imported mechanical seal for double waterproof protection.3. Design with Oil Chamber, provides for the most durable seal design, lubrication and cooling.4. Motor with Thermal Protector to prevent motor failure due to pump problem or accidental run-dry conditions.5. Internal wires connect by terminal design, solid and reliable.6. Power cable rubber seal designed by filling epoxy to raise humidity-resistance.7. Each pump with laser printed serial number to record the production date.8. All pumps are 100% tested in pump head line and completed pump production line.9. The special test all the pumps will perform is the low voltage start-up test.
