All Size Top Quality MPPT Controller DC Brushless Submersible Solar Water Pump

Basic Info.

Model NO.	3SPS
Assembly	Booster Pump
Power	Solar Energy
Start Up	Electric Pump
Type	Positive-Displacement Pump
Application	Submersible Pump, Clarified Water Pump
Industry	Fisheries Pump
Media	Sea Water Pump
Performance	Automatic Pump
Theory	Rotary Pump
Size	2inches -10 Inches
Meaterial	Stainless Steel 304, 316
Motor	DC 12V - 120V
Max Head	30 - 280 Meters
Controller	Quality MPPT Controller
Max Flow	1 - 160 M3/Hr
Transport Package	Wooden Carton for Exportation Standard
Specification	CE, RoHS,
Trademark	Rison
Origin	Zhejiang, China
HS Code	8413709190
Production Capacity	8000 Sets/Month

Product Description

All Size Top Quality MPPT Controller DC Brushless Submersible Solar Water Pump( 3 Years Warranty )( 3 ~ 6 Inches Submersible & Surface Solar Pump )

DC Submersible Solar Pump for Irrigation and Residential

Solar panels is to convert sunlight into electrical energy which will be passed to the solar pump controller,the energy will be used to power the pump. Solar Controller /Inverte is used to stabilize the power voltage and output the power to drive the electric motor of the pump. If backup batteries (optional) are available, then the pump controller can charge them.Battery is for Storaging the additional energy that can be used at later time when the sunlight may not be adequate to drive the pump.Water Level detector / Sensors is used to connected to the controller and can be used to protect the pump from running dry as well as to automatically turn the pump off when a water tank is full.
RISON MPPT Controller Advantage

	RISON MPPT CONTROLLER	CONTROLLER FROM OTHER COMPETITORS
Automatically	Totally Automatically restarting every morning, or when the sun appears after cloud	Not steady, and cannot restart automatically
Efficiency	15-20% higher than common Controller	Lower efficiency
MPPT Fuction	With MPPT function(Maximum Power Point Tracking )	No MPPT
Input Voltage Range	Increase much larger inpt voltage range to 100V. Will make the panel selection very easy, also avoid too higher input voltage burn the controller	Very smaller input voltage range largest only to 85V, and will be burrnt if the panel voltage increase during the very shinning daytime;
Protection Against Wrong Connection	Protecting against being burned, in case some customers reversed panel"+"/"-"terminals, when connecting onto controller.	No protection, will be burned definitely
Protection Against overvoltage/current	The controller will just keep silent(stop working), when the input voltage/ current is beyond the controllers tolerance;	The controller will be burned;
High Temperature Resistance	Can run well under 50 degrees condition for 24 hours continually;	Will be burned immediately when temperature more than 40 degrees;
Operation	Very convenient to open the Box to change the SPEED SWITCH;	Not convenient, needs screwdriver to open the 4 bolts everytime;
Warranty	3 years	No warranty or longest as 1 year;
